PIP (picture in picture) and POP (side by side) are standard functions in each processing module. Complete curved screen edge blending can be achieved through remote controller and Ethernet without additional devices except for signal source and projectors.
User can also adjust image aspect ratio through Video Wall Overlap function. Video wall function in M800 is to crop and allocate source image for each projector and set overlap pixels for edge blending. HDMI loop out supports daisy chain connection up to 8k/2k / 4096x2160 and allows large display with multiple M800 cascaded. It provides more flexible system configuration. Image 90/180/270 degrees rotation and flip with 4k/60 input from various input sources are embedded. Users can see real time geometry and color adjustment to get optimized result. Separate R, G, B gamma correction for edge blending region color fine-tune, individual color correction for each output and 9 regions non-edge blending area black level uplift are also standard functions in M800. Linearity Grid Line Adjustment and Corner Wall image adjustment for mapping image at 90 degrees corner wall is a new function in geometry alignment.
User can use IR controller, USB, WebGui and Ethernet to perform edge blending and sophisticated geometry alignment up to 17x17 control points.
Programmable EDID can optimize input timing to get the best video result.Īdvanced warp technology is embedded in M800. Output supports up to WUXGA or 2048*1080 It is integrated with 10-bit high end processor, motion adaptive de-interlace, low angle smooth algorithm, 3:2/2:2 pull-down and supports non-VESA standard input timing. M803 is for 3 projectors and M804 is for 4 projectors. Multiple M800 can be configured for various projectors and large scale display.Įach processing module has 4 input ports (2x HDMI, 1x DP, 1x VGA), one HDMI loop out port for daisy chain connection and 1x HDMI outputs. M802 is integrated with two processing moduels for two projectors. M801 is integrated with one processing moduel for control one projector. M800 has 4 models to control from one projectors up to four projectors.
